SC2000 Milbeaut 360-degree Image Processor with Computer Vision
"SC2000”, also known as the "M10V" from the family of Milbeaut®series SoCs, is quipped with a digital signal processor optimized for computer vision, it also features advanced functionalities such as 360-degree, real-time omnidirectional stitching with multi cameras, image stabilization without mechanical gimbals, and rolling shutter correction.
The image processor performs up to 1.2Giga pixel per second, three times faster than the previous design, while the power consumption is lower than 1.7W under typical operating conditions. SC2000 is suitable for action camera, drone camera, and support devices and applications requiring high-performance and low-power consumption image processing capabilities.
Applications
- Action cameras
- Surveillance cameras
- UAVs and drones
- Handheld/ mobile applications
Features
- 4 Camera Stitching
Videos are stitched from 4 cameras (Max : 4K 30fps). Fish-eye lens can be used for wider field angle video capture by correcting distortion in real time.
View a quick demo video using two cameras to form a 360-degree omnidirectional view:
- Slow Motion in Full HD 240fps Video
Full HD video replay in slow motion with variable frame rate. Captured video can be viewed in slow motion using a playback adjustable frame rate application.
- HDR (High Dynamic Range)
HDR feature prevents under/over exposures and captures more vivid and detailed image in difficult scenes such as backlight, high contrast, and night scenes. Available for both still and video captures up to 30fps in full HD.
Specifications
| ISP Process | 28nm |
|---|---|
| Product Structure | PoP |
| CPU | CortexA7-Quad 650MHz |
| Package size | 15mm, 0.5mm pitch |
| SDRAM type | LPDDR-3 |
| Image Processing rate | Max 1.2Gpixel/sec |
| Max Pixel Size | No Limitation |
| Sensor I/F | MIPI Rx(4lane) 2.5Gbps x 4ch |
| S-LVDS(16lane/4clk) 1.0Gbps | |
| SLVS-EC(8lane) 2.5Gbps x 4ch | |
| Host I/F | PCI-e, USB3.0 |
| LCD I/F | MIPI-DSI/16bit Parallel |
| TV I/F | HDMI 2.0 |
| Video Codec | H264 4Kp30/HEVC 4Kp60 |
| Chroma NR(Suppre) | ○(Hardware) |
| Bayer NR(ELF) | ○(Hardware) |
| Lens Distortion Correction | ○(Hardware) |
| Face Detection | ○(Hardware Assist) |
| Smile/Blink Detection | ○(Hardware Assist) |
| High Dynamic Range(HDR) | ○(Hardware) |
| EIS(Electronic Image Stabilization) | ○(Hardware) |
| Defect Pixel Correction | ○(Hardware) |
| Color Aberration | ○(Hardware) |
| 3DNR | ○(Hardware) |
