Milbeaut™ Image Processor "MB86S22AA"
The Socionext “MB86S22AA" series has twice the processing performance compared to conventional products. It also features H.264/AVC compression and decompression for video capture and processing in Full HD (p30 and i60) algorithms. The MB86S22AA offers the best-quality, highest-speed image processing which is ideally suited for digital cameras makers.
Features
- Imaging processor Milbeaut M-7M Series "MB86S22AA" provides an ideal solution for high-resolution, high-performance image processing in digital SLRs and high-end compact digital cameras
- Substantially building on the company's previous image processing algorithms, which boast a strong industry track record, the new chip enables roughly twice the processing performance of existing products
- H.264/AVC compression and decompression in Full HD 30p and 60i video
- The newly developed IIP (Integrated Image Processor) circuit increases processing speed and performance
- A new image processing algorithm with greatly improved optical correction capabilities
- Faster processing thanks to a newly developed Integrated Image Processor circuit
- Improved high dynamic range (HDR) photograph quality using a JPEG-HDR™ format developed by Dolby Laboratories.
Video
- MPEG4/AVC(H.264) High/Main Profile Level4.0 1080/i60 1080/p30
Continuous Shooting
- Bayer Continuous shooting : 25Mpix/20fps
- JPEG Continuous shooting : 25Mpix/10fps
Intelligent Image and Video Processing
- 3D Video Capture and Recording Application
- Face Detection
- Video Stabilization
- 3D Noise Reduction
- Object Tracking
- WDR (Wide Dynamic Range)
- Scene Detection
- HDR (High Dynamic Range)
- Jagged or Uneven Surface Reduction
- Continuous Auto Focus
[Jagged or Uneven Surface Reduction]
[HDR - High Dynamic Range]
Distortion Correction
- Distortion correction can be achieved using hardware macro
[Distortion Correction]
Specifications
- CPU: ARM Cortex-A5MP
- Maximum image processing speed equivalent to12fps at 24M pixels
- Hardware assist capable of feature extraction
- Improved lens correction, lens distortion correction, lens resolution correction
- Accelerated multi-frame operation
- High speed and intelligent bus arbitration
| ISP Process | 55nm CMOS Technology |
|---|---|
| Package Size | Ball Pitch 0.5mm |
| Body size 15mm x 15mm | |
| CPU | ARM Cortex-A5 MPCore(Dual Core) |
| Video Codec | H.264 1080/i60, 1080/p30 |
| Image Processing rate | 500Mpix/sec |
| Max Image Size | 5.8K Pixel(Horizontal) |
| Sensor Interface | Parallel：12bit 1ch |
| Serial: sub-LVDS 12Lane, SLVS 8Lane | |
| Host Interface | UART/CSIO 6ch, USB2.0 High-Speed |
| LCD Interface | Composite(NTSC,PAL), D-LCD, HDMI |
| Card Interface | NandFlash 1ch, SDCard 2ch |
| Continuous Shooting | 25M/10fps |
| Face Detection | Support(Hardware) |
| Distortion Correction | Support(Hardware) |
| Video Stabilization | Support(Hardware) |
| Still Stabilization | Support(Hardware) |
| Jaggy Reduction | Support(Hardware) |
